5V Usb Charger
  • 5V Usb Charger
  • 5V Usb Charger

5V Usb Charger

    short / Over current protection, over voltage protection, over temperature protection.

Inquire Now None
  • Description
body size61.5*26.8*34.3mm
Input Rated Voltage86Vac～264Vac
Input Frequency Range47Hz～63Hz
Input Current0.3A(Max)
Input Inrush Current50A
Efficiency78.8% ,level VI
DC Output Voltage12v±5%
DC Output Rated Current500mA
DC Output Power6w
Ripple and Noise≤80Mv
Turn On Delay Time≤3S (AC:110V and full load)
StandardUL/CUL FCC SAA C-TICK
DC cable length1.5m 2464 type
DC connector5.5*2.1*12mm striaght type
Dielectric Withstand VoltageA IEC320 3 pin input---output(FG)3000Vac 1 m
Protectionshort / Over current protection, over voltage protection, over temperature protection.
Leakage Current≤5Ma
Operating Temperature Range0℃----+55℃
Storage Temperature-20℃----+85℃
