12v 8a 10a power supply
100-240V AC input 50/60HZ, DC 12V 8Amp / 10Amp output, 120Watt max wattage
Convert 100-240V AC to 12V DC, widely use for SMD2835 3528 5050 RGB LED strip lights, LED string, wireless routers, ADSL Cats, HUB, switch, security camera, Audio/Video power supply
Please be kindly informed that the total wattage of your device should not exceed the max wattage（120 Watt) of this adapter
1 x 12V 8A / 10A 120W ( max ) power supply with customers requested connector ( optional )
With 3 year warranty, and our seller support team always stand behind our products in any way, so please contact us for solution if you have any quality problems
have 2pin and 3pin ac socket for selection
Inquire Now
None
- Description
| body size | 160*60*35mm |
| Input Rated Voltage | 86Vac～264Vac |
| Input Frequency Range | 47Hz～63Hz |
| Input Current | 0.8A(Max) |
| Input Inrush Current | 50A |
| Efficiency | 88%, level VI |
| DC Output Voltage | 12v± 5% |
| DC Output Rated Current | 10A / 8A |
| DC Output Power | 120w ( max ) |
| Ripple and Noise | ≤180Mv |
| Turn On Delay Time | ≤3S (AC:110V and full load) |
| Standard | UL/CUL FCC CE CB |
| DC cable length | 1.2m 2464 type ( optional ) |
| DC connector | 5.5*2.1/2.5*12mm ( optional ) |
| Dielectric Withstand Voltage | A IEC320 3 pin input---output(FG)3K Vac 1 m |
| Protection | OVP ,OCP,SCP,OTP |
| Leakage Current | ≤5Ma |
| Operating Temperature Range | 0℃----+55℃ |
| Storage Temperature | -20℃----+85℃ |
